Gallagher Electric Fence Installation Instructions
Gallagher electric fences are designed for livestock control, perimeter security, and wildlife management. Proper installation ensures maximum effectiveness, safety, and durability. This guide provides step-by-step instructions to set up your Gallagher electric fence system.
Tools & Materials Required
✔ Gallagher Fence Energizer (battery, solar, or mains-powered)
✔ Fence Wire (polywire, high-tensile, or tape)
✔ Grounding System (galvanized ground rods)
✔ Insulators (to prevent power loss)
✔ Fence Posts (wood, metal, or fiberglass)
✔ Voltage Tester (to check output)
✔ Cutting & Tensioning Tools
Step-by-Step Installation Guide
1. Plan Your Fence Layout
- Determine fence boundaries and install corner posts first.
- Space posts 10-30 feet apart (depending on wire type).
- Consider number of wires needed (single-wire or multi-strand).
2. Install Fence Posts & Insulators
- Wood posts require nail-on or screw-on insulators.
- Metal or T-posts use clip-on insulators.
- Place insulators at the desired wire height for livestock type.
3. Set Up the Grounding System
- Use at least 3 ground rods, 6-8 feet deep, spaced 10 feet apart.
- Connect rods with galvanized wire and attach them to the energizer's ground terminal.
- Proper grounding ensures maximum shock power.
4. Install the Fence Wire
- Attach wire to insulators tightly but not too tight to allow slight movement.
- Use strainers for tensioning high-tensile wire.
- If using polywire or tape, use a ratchet tensioner.
5. Connect to the Energizer
- Attach the positive (hot) wire from the energizer to the fence wire.
- Attach the ground wire from the energizer to the grounding system.
- Plug in the energizer or connect it to a battery/solar panel.
6. Test & Maintain the Fence
✔ Use a voltage tester to ensure 5,000V – 10,000V output.
✔ Regularly check for breaks, vegetation interference, or loose connections.
✔ Clean ground rods periodically to maintain conductivity.
Troubleshooting Common Issues
1. Low or No Voltage
✅ Ensure the grounding system is properly installed.
✅ Remove vegetation touching the fence.
✅ Check for broken wires or poor connections.
2. Energizer Not Working
✅ Confirm power supply (battery charged, solar panel functional, or outlet working).
✅ Check fuses or internal connections.
3. Short Circuits on Fence
✅ Make sure insulators are in place.
✅ Check for damaged or loose wires touching metal posts.
Conclusion
A Gallagher electric fence provides effective security and animal control when installed correctly. Following these step-by-step instructions, ensuring proper grounding, and performing regular maintenance will keep your electric fence functioning at peak efficiency.
